nema16 39HM 2 phase 0.9° hybrid stepper motor
nema16 39HM 2 phase 0.9°  hybrid stepper motor
Quick Detail:
ItemSpecifications
Step Angle Accuracy±5%
Resistance Accuracy±10%
Inductance Accuracy±20%
Temperature Rise80℃ Max
Ambient Temperature-20℃~+50℃
Insulation Resistance100MΩMin.500VDC
Dielectric Strength500VAC for one minute
Shaft Radial Play0.02Max.(450g-load)
Shaft Axial Play0.08Max.(450g-load)



Model NoStep
Angle
(°)
Rated
Voltage
(V)
Rated
Current
(A)
Phase
Resistance
(Ω)
Phase
Inductance
(mH)
Holding
Torque
(Kg.cm)
Detent
Torque
(g.cm Max)
Rotor
Inertia
(g.cm²)
Motor
Length
(mm)
Leads No.Motor
Weight
(g)
39HM20-05040.94.0 0.588.40.85015204100
39HM26-05060.9120.5241315011266150
39HM26-06040.95.4 0.69161.45018264150
39HM33-04060.9120.430161.212023336160
39HM33-06040.95.40.69151.612023334160
39HM33-12040.931.22.53.61.612023334160
39HM40-04060.9120.430261.818030406210
39HM40-06040.97.20.612202.218030404210
39HM40-12040.93.841.23.25.52.218030404210
Above only for representative products, products of special request can be made according to the customer request.
